Frame | Wave, aluminum | Rear brake | Shimano, BR-MT200, hydraulic disc brake |
Rigid fork | HoheAcht, aluminum | Brake disc front | Shimano, SM-RT30, 180 mm, center lock |
Handlebar | HoheAcht, 31.8 mm, width 640 mm, bend 25°, rise 25 mm, aluminum, black | Brake disc rear | Shimano, RT-EM300, 180 mm, center lock |
Stem | HoheAcht, 31,8 mm, 90 mm, 0-60°, aluminum, black | Saddle | Selle Royal, Nuvola 5060 DRC |
Grips | Herrmans, LINE, 124 mm / 90 mm | Seatpost | HoheAcht, Seatpost 2D, 31,6 mm x 350 mm, 10 mm offset, aluminum |
Headset | ACROS, zs56, zs66, industrial bearings, integrated cable routing | Rack | AtranVelo, Tour 365 BS H-Cargo, 27 kg payload |
Rim | Mach1, Trucky 30, 27.5'', aluminum, black | Front light |
Herrmans, H-BLACK MR8 E-BIKE 6-12 V, LED, 3.3 W, 180 lm, reflector |
Wheel size | 27.5 inch | Rear light | Herrmans, H-CARGO E-BIKE 6-12 V, 4 LEDs, 0.6 W, integrated, parking light, BR-12 reflector |
Tyres | Continental, CONTACT Cruiser, 27.5'' x 2.4'' (60-584), reflex | Mudguard |
SKS, PET, wheel protection, A69R, 28 Zoll |
Front wheel hub | Formula, CL-811, Disc, 15 x 110 mm, industrial bearings | Battery & frame lock |
ABUS, 5755L NR BK OE; ABUS, BLO SHI IT2 X+ |
Rear wheel hub | Shimano, Nexus, SG-C6001, 8-speed, freewheel, center lock | Side stand |
AtranVelo, Rex HV, KSA 40 |
Sprocket | Gates, CDX pulley, 22 teeth | Pedals | Marwi, SP-828 black SBL, aluminum with PP |
Drive Belt | Gates, 122T CDX, blue | Motor | Shimano Steps, DU-EP6, 25km/h, 85 Nm, mid-motor |
Crankset | Chainring Gates, 46T CDX + Spider + trouser guard ring, aluminum | Battery |
Shimano Steps, BT-E8036, 630 Wh, integrated |
Crank arm set Shimano Steps, FC-E6100, 175 mm | Display | Shimano Steps, SC-E6100, Bluetooth, ANT private | |
Derailleur | Shimano Steps, Nexus SG-C6001, 8-speed hub gear, freewheel | Charger | Shimano Steps, EC-E6002, 2 A |
Shift lever | Shimano, Nexus, SL-C6000, 8 speed | Weight | From 27,0 kg |
Front brake | Shimano, BR-MT200, hydraulic disc brake | Max. permissible weight | 150 kg |
General product information: Prices and colors are subject to change. TechniBike reserves the right to replace named components from one manufacturer with equivalents from another well-known manufacturer if they are not available. The weights of the bikes are based on painted pre-production frames at the time of publication, the actual weight may also vary.
Frame size (cm) |
42 |
48 |
55 |
Seat tube (mm) |
420 |
480 |
550 |
Top tube horizontal (mm) |
600 |
620 |
645 |
Head tube (mm) |
175 |
175 |
195 |
Wheelbase (mm) |
1162,7 |
1182,7 |
1209,5 |
Chainstays (mm) |
484 |
484 |
484 |
Bottom bracket height (mm) |
286 |
286 |
286 |
Head tube angle (°) |
69 |
69 |
69 |
Seat angle (°) |
74 |
74 |
74 |
Stack (mm) |
661 |
661 |
680 |
Reach (mm) |
410 |
430 |
450 |
Body height (cm) | 155 - 165 | 165 - 175 | 175 - 185 |
